Crawler mounted concrete pump 90 m³/h SEBHSA BD-3907.OR

The SEBHSA BD-3907.OR Crawler-mounted concrete pump meets the highest requirements with its maximum concrete production capacity.
The SEBHSA BD-3907.OR Crawler-mounted concrete pump meets the highest requirements with its maximum concrete production capacity.

Powerful built, the SEBHSA BD-3907.OR is the general purpose pump for any kind of foundation challenge that meets the highest demands with its capacity:
Maximum concrete output: 90 m³/h
Maximum concrete pressure: 70 bar

Combining high performance with absolute reliability and low maintenance cost the crawler-mounted concrete pump SEBHSA BD-3907.OR is the answer to almost any foundation or ground related challenge.

Its impressive production capacity of 90m³/h or 70bar is easily adjustable; thus making it the pump of choice for many of the biggest construction and foundation projects, underpinning airports, port and rail or motorway infrastructure. Suitable for piles, caissons or retaining walls of almost any diameter or depth and designed for deep foundation and ground improvement, the strong performance of the pump enables its use for any kind of concrete pumping or conveyance.

Key features

  • Wide choice of engine and emission standards as well as a limitless range of accessories to satisfy the most exigent legislation and customer demands.
  • Large diameter swing valve and cylinders enable the use of cost effective concrete mixes containing coarse aggregates.
  • Extra big pump cylinder increase output, while reducing pump cycles and thus wear & tear.
  • Lifetime guarantee for the availability of wear and spare parts.

Technical specifications

Diesel engine
Max. flow output
Max. concrete pressure
D. pumping cylinders
129 kW
90 m³/h
70 bar
200 Ø x 1400 mm
Spec. Crawler mounted concrete pump 90 m³/h SEBHSA BD-3907.OR.pdf1,39 MB
